Yetter 8500-027
Features
- Twin rest brackets with 12" pads fit standard or draper platforms and folding or standard corn heads
- Full-length upper bar features tool-free universal angle position supports
- Works with Yetter Stalk Devastator™ rollers and most stalk stompers from other manufacturers
- Central-beam design has adjustable lower and upper positioning supports
- Upper bar is open and can store an extra sickle
- Standard front fenders help prevent rocks and debris from damaging the head or truck
- LED lighting system and full-length reflective tape meet D.O.T. regulations, allowing for safe towing day and night
- Includes two safety chains, standard electric breakaway brake system, powder-coated finish, and seven-pin wiring plug
- Standard toolbox allows for storage of straps and header parts with the cart
- Includes two fully adjustable straps for securing heads for transport
- Includes standard clevis hitch; ball hitch is optional
- Includes telescoping tongue for faster, easier hookup
- Tongue rotates around to main beam for easy storage and shipment
- Optional marker pole kit allows for easy alignment when setting head on the cart
Specifications
MODEL |
8500-027 |
Overall Length (in.) |
429 |
Overall Width (in.) |
102 |
Overall Height (in.) |
44 |
Unloaded Weight (lbs.) |
3,260 |
Max Gross Weight (lbs.) |
12,000 |
Max Usable Weight (lbs.) |
8,740 |
Max Drawbar Pull (lbs.) |
17,600 |
Chassis Style |
Single Beam |
Axle Configuration |
Single |
Axle Stud Pattern |
8" x 9/16" |
Tire Size |
8 |
Max Tire PSI |
65 |
Electric Brakes |
Standard |
Cutter Bar Storage |
Standard |
Lights |
Standard |
Front Fenders |
Standard |
Accessory Box |
Standard |
License Plate Lights |
Wire Leads Only |
Marker Pole Kit |
Optional |
