• Depth Gauges
  The Battle Ax rotor design uses built-in depth gauges to control cutting depth, like raker teeth on a chainsaw.
• Two-Stage Cutting Chamber
  Two shear bars allow the Battle Ax to produce a finer mulch with fewer passes. The primary shear bar is adjustable for controlling particle sizes.
• Convenient Tooth Mounting
  The cutting teeth are mounted to the rotor with a single bolt. They can be easily reversed, replaced or removed on the jobsite using a common hex socket.
• High-Performance Teeth Options
  Choose from 4-point beaver teeth, Quadco reversible planer blades or double carbide teeth.
• Fixed-Displacement Gear Motor
  The high-pressure gear motor is a reliable, cost-effective workhorse. It is for use with case drain.
• Synchronous Belt Drive
  The positive drive, cog belt and sprocket design maximizes efficiency and requires less maintenance than other drive types.
• Machined Anti-Wrap Bearing Protection
  Rotor ends are machine turned to mate with close tolerance, machined anti-wrap rings, which minimize debris in the bearing chamber.
• Adjustable Push Bar
  Constructed with integrated, welded claw hooks, the bar helps push falling trees and brush away from the power unit, while also allowing them to be properly positioned for efficient feeding into the head.
• Performance Monitoring
  An integrated PSI gauge that monitors the hydraulic load is positioned for easy viewing from the skid steer cab. It helps keep the Battle Ax at the optimum hydraulic load for peak performance throughout an application.
• Premium Strength Steel Housing
  All body components are laser cut from premium strength steel. Also, abrasion resistant steel is used in high-wear areas
• Steel Deflector Chains
  Running the entire length of the mulching attachment, steel deflector chains improve safety by reducing flying debris.
• Maximum Visibility
  The Battle Ax is designed for maximum visibility from the skid steer cab, which increases safety, productivity and efficiency.
• Universal Skid Steer Mount
  The universal mount allows the Battle Ax to be easily used with any brand or model of skid steer or compact track loader.
• Hydraulic Hose Routing
  Hoses are right sized and routed to reduce the chance of binding, yet are long enough for a full range of motion without damage. Hoses are included, couplers are not.
• 13.5-Inch-Diameter Rotor
• 1-3/4″ Piloted Double Taper Roller Bearings

Specifications and data are subject to change without notice.
