Spout

• Hydraulic spout rotation
• Gear-driven spout 270 degrees
• 11-inch diameter: 841S
• 14-inch diameter: 961S
• Manually adjustable deflector (hydraulic optional)

Discharge Fan

• 27-inch diameter housing, 3 blades, 8-inch-deep fan housing: 841S
• 30-inch diameter housing, 4 blade, 11-inch deep fan housing: 961S
• 540 RPM only

Augers

• Heavy-duty open-spoke design
• 16-inch: 841S
• 24-inch: 961S

Cutting Capacity

• 32-inch cutting height and 84-inch width: 841S
• 40-inch cutting height and 96-inch width: 961S

Gearbox

• 120 HP oil-bath gearbox

Mount

• Standard three-point hitch
  • Category I or II welded hitch: 841S
• Designed for free-link only
• • Category II or III (Quick-hitch only): 961S

Easy-Access Shear Bolts

• PTO shaft
• Auger drive sprocket
• Auger driven sprocket

The Nuts and Bolts

Drive and Power Requirements

• 540 RPM PTO only
• 40 to 120 HP

Components

• No. 60 roller chain
• 1-1/2-inch auger bearings
• Replaceable hardened steel, bolt-on cutting edge
• Adjustable skid shoes

Construction

• High-quality craftsmanship
• Laser-cut components
• 12-gauge steel body
• 1/4-inch end plates
• 3/8-inch auger flighting
