Spout

• Hydraulic spout rotator
• 14-inch diameter
• Gear-driven spout with 270 degrees of movement
• Truck-loading spout options available
• Manually adjustable deflector (hydraulic optional)

Discharge Fan

• 36-inch diameter
• 12-inch deep fan housing

Augers

• 16-inch diameter, open-spoke augers
• Lateral auger-locking device

Cutting Capacity

• Dual augers: 48-inch cutting height
• Triple augers: 66-inch cutting height
• Available in 108- and 120-inch widths

Gearbox

• 200 HP reduction gearbox

Hitch

• Heavily reinforced Category II or III welded three-point hitch (quick hitch required)
• Hitch stand included

Easy-Access Shear Bolts

• PTO shaft
• Auger drive sprocket
• Auger driven sprocket

The Nuts and Bolts

Drive and Power Requirements

• Input: 1,000 RPM tractor PTO
• Output: 540 fan speed
• 140 to 200 HP
• Easy access shear bolt protection

Components

• No. 80 roller chain
• 1 1/2-inch bearings
• Replaceable hardened steel, bolt-on cutting edge
• Extra-large adjustable skid shoes

Construction

• High-quality craftsmanship
• Laser-cut components
• 10-gauge steel body
• 5/16-inch reinforced end plates
• 3/8-inch auger flighting
