Spout

• 14-inch diameter
• Gear-driven spout 270 degrees
• Manually adjustable deflector (hydraulic optional)

Discharge Fan

• 30-inch diameter housing, 4 blades
• 11-inch deep fan housing

Augers

• Two 16-inch diameter open-spoke augers
• Lateral auger-locking device

Cutting Capacity

• 48-inch cutting height
• Available in 96- and 108-inch widths

Gearbox

• 200 HP reduction gearbox

Mount

• Heavy-duty reinforced three-point hitch
• Category II or III Quick Hitch
• Category III without Quick Hitch
• Hitch stand included

Easy-Access Shear Bolts

• PTO shaft
• Auger drive sprocket 3/8 gr. 2
• Auger driven sprocket 3/8 gr. 5

The Nuts and Bolts

Drive and Power Requirements

• 150-200 HP front PTO, 1,000 RPM CCW rotation only
• 1 3/8 6B spline (540 spline)
• 1 3/8 21 spline (1,000 spline)
• 1 3/4 20 spline (big 1,000 spline)

Components

• No. 80 roller chain
• 1 1/2-inch bearings
• Replaceable hardened steel, bolt-on cutting edge
• Extra-large adjustable skid shoes

Construction

• High-quality craftsmanship
• Laser-cut components
• 10-gage steel body
• 1/4-inch reinforced end plates
• 3/8-inch auger flighting
