Shortest Hitch-to-Axle Length

Shortest hitch-to-axle length (14'-0") allows the applicator to follow directly behind the tractor, creating just one set of tracks that reduces crop damage and eliminates the need for a steerable hitch option.

Hydraulic Wing Kick

15° Hydraulic Wing Kick Reduces Crop Damage When Turning

Parallel linkage toolbar design keeps the coulters and knives in correct position to the ground at all times. Wing sections allow 15° upward and 10° downward movement for consistent application over uneven terrain.

Ball Flow Monitors

Standard flow monitors allow the operator to see the rate of flow to each coulter using a floating ball located inside the transparent inspection tube. Each coulter is connected to the flow monitors with a separate supply hose.

Safety Rinse Tank

Provides 9 gallons of rinse water located at an easily accessible height.

More Standard Features

• Easily-accessible jack that pins away for storage
• High-strength toolbar built with double 5"×7" tubing
• Parallel linkage toolbar design keeps the coulters and knives in correct position to the ground at all times
• Diaphragm shut-off valves at each coulter reduces fertilizer loss and crop "burn" damage on end rows
• Choice of knife or injection delivery
• Coulters feature heavy-duty square tube mounting pillars with high-strength ⅝" U-bolts and 8-bolt hubs on a 60° swivel for maximum performance
• Choose from two coulter options: straight blade with ripple or ⅝" wavy
• Tool-less gauge wheel height adjustment
• Recommended horsepower: 275 hp to 410 hp
• Greaseless toolbar bushings for reduced maintenance
