Berlon Attachments SKLGR-78
Skeleton Rock Grapple SKLGR-78
Overview:
Common uses include: Bucket is ideal for rock picking,
clearing fence lines, construction, scrap metal and
other clean-up applications.
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Features
Features
- 3/8” thick ribs spaced 3” apart, are fully welded on both sides
- (2) 1-1/4” solid steel rods run through the ribs and are welded for greater structural integrity
- Cylinders - 3,000 lb., 2.5” bore
- Deep-well rock dam keeps material in place while your are transporting or picking up more material
- Fully welded leading edge
- Dual, independent claws
- Scrap ends, hoses & couplers, hose saver and needle valve included
Options
- Bolt-On Ends
Specifications
| Model | SKLGR-78 |
| Inside Dimension (in.) | 78 |
| Outside Dimension (in.) | 79.5 |
| "A" Height (in.) | 21 |
| "B" Depth (in.) | 42 |
| "C" Angle (deg.) | 70 Degree angle |
| "D" Grapple Opening (in.) | 34.5 |
| Weight (lbs.) | 1278 |
| Space between Tines (in.) | 3 |
| Tine Thickness (in.) | 3/8" |
| HD Package | N/A |
| Inlcudes MPUF-1HD Universal mounting plate. Other options available. |
