Berlon Attachments MLB-48x72
Material Long Bucket MLB-48x72
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Features
Features
- Heavy wall frame and 1/2” thick side plates
- Gusseted construction (60” wide and greater)
- 1/2” x 6” weld-on edge with holes
- Custom sizes also available
- Heavy-duty universal mounting plate is standard; other mounts available
- Bolt-On Cutting Edge
Options
- Bolt-On Rake Tooth Edge
- Bolt-On Tooth Bar
- Bolt-On Tooth Bar, Over Bolt-On Edge
Specifications
| MLB Series (Model No.) | MLB-48x72 |
| Inside Dimensions (in.) | 48 |
| Outside Dimensions (in.) | 49.5 |
| "A" Height (in.) | 21 |
| "B" Depth (in.) | 72 |
| "C" Angle (Deg.) | N/A |
| Weight (lbs.) | 800 |
| Heaped Capacity (cu. Ft.) | N/A |
| Wear-Bars (1/2" x 3") | 3 |
| Dimple Plate | N/A |
| HD Package | Standard |
